Rongda Vr-231

Rongda Vr-231

Model VR-231
Configuration Desktop
Operation mode Button press
Mastering mode High speed digital thermal plate master-making
Scan mode Document feeding
Printing mode Fully automatic stencil printing
Original type Sheet/Two-in-one
Image Processing Mode Text/Picture/Text&picture
Master-making speed 19s
Resolution 300*400dpi
Original size(min/max) 100*148mm(min) ~297*420mm(max)
Scan area(max) 204*291mm(A4) switch to 204*358mm(A4L)
Printing area(max) 204*291mm(A4) switch to 204*358mm(A4L)
Paper size(min/max) 100*148mm(min) ~260*386mm(max)
Paper weight(min/max) 40~120g/m2
Paper feeding capacity 500 pages(70gsm)
Paper receiving capacity 800pages(70gsm)
Print reproduction Ratio no
Print speed Five Steps Variable (50,70,85,105,120 ppm)
Scan density 5 variable ( lighter, middle, dark, darker)
Master density 5 variable ( lighter,, middle, dark, darker)
Image position/
Print Position Adjustment Horizental:±10mm,Vertical±10mm
Master eject capacity 10 sheets
Optional parts no
Standard Features Master-making density adjustment, scanning density adjustment, computer connection(master making), space position adjustment,printing density adjustment, energy save
Optional function Auto shut off, Network printing function, Auto-print pressure adjustment
Power supply 220~240V/50/60Hz
Dimensions (DxWxH) Using: 1200*620*500mm, Storage: 707*707*735mm
Net weight(Kg) Approx. 59
