Single- and multi-page TIFF
Single-page JPEG
Single- and multi-page PDF, PDF/A
Single- and multi-page high-compression PDF
Scan to email
Protocols
SMTP gateway, POP, IMAP 4
Authentication
SMTP authentication, POP before SMTP authenticationScan resolution
100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi,
600 x 600 dpi; default 200 x 200 dpiScan to email file types Single-page
TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDFMulti-page
TIFF, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDFNote: Optional OCR unit is required to support scanning to a searchable PDF.
Scan to folder
Protocols SMB, FTPSecurity
Client folder logon, transmission encryption of logon name and passwordResolution
100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi,
600 x 600 dpi; default 200 x 200 dpiSearch for client folders SMB—browsing directly to the designated folder
FTP—by folder nameScan to folder file types Single-page
TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF
Multi-page
TIFF, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF
Note: Optional OCR unit is required to support scanning to a searchable PDF.
Standard input capacity (sheets)
1,200
Maximum input capacity (sheets)
4,700
Standard output capacity (sheets)
500
Maximum output capacity (sheets)
1,625
Paper input configuration – standard
2 x 550-sheet paper trays, 100-sheet bypass tray, duplex unit
Paper output configuration – standard
500-sheet face-down internal output tray
Supported media
Tray 1 and 2
Plain paper, recycled paper, colour paper, special paper, letterhead, preprinted paper, bond paper, card stock, plain paper backside, envelope, thin paper, plain paper 1–2, middle thick, thick paper 1–4
Bypass tray
Plain paper, recycled paper, colour paper, special paper, letterhead, preprinted paper, bond paper, card stock, OHP, label, plain paper backside, envelope, thin paper, plain paper 1–2, middle thick, thick paper 1–4
Note: Plain paper is not displayed as a paper type.
Maximum paper sizeSRA3Media weight (g/m2)52–300
Interfaces – standard
Mainframe
10Base-T/100Base-Tx (Ethernet)
1000Base-T (Gigabit Ethernet)
USB Host Type A—2 ports
USB Type B—1 portSmart Operation Panel
IEEE 802.11 b/g/n (Wireless LAN)1
Bluetooth2
SD card slot—SDHC memory card
USB Host Type A—USB Flash memory
USB Host Type A—1 port for USB keyboard2
USB Host Type mini B—for NFC card reader2
NFC tag21—Limited printing for a peer-to-peer mobile device via RICOH Smart Device Connector 2—Cannot be used for printing
Interfaces – optional
IEEE 1284
IEEE 802.11a/g/n (Wireless LAN)
Device Server Option Type M37 (additional Ethernet/Gigabit Ethernet port)
Windows 8.1
Windows Server 2012
Windows Server 2012 R2
Windows 10
Windows Server 2016
Windows Server 2019
Macintosh
OS X Native v10.13 or later—PostScript 3 only
Unix
Sun Solaris—10
HP-UX—11.x, 11iv2, 11iv3
Red Hat Linux—Enterprise, 4.x, 5.x, 6.x
SCO OpenServer—5.0.7, 6.0
IBM AIX— 6.1, 7.1, 7.2
SAP
Environment—R/3, S/4
Platform—SAP R/3 (Release versions 3.0 and higher), SAP R/3 Enterprise, mySAP ERP (2004 and higher), SAP HANA
Page Description Language (PDL)—PCL
Character set—Latin-1, Latin-2, Unicode
Barcode fonts—Code 128, Code 39, Code 93, Codabar, 2 of 5 interleaved/Industrial/Matrix, MSI, USPS Postnet, UPC/EAN
OCR fonts—OCR A, OCR B
Other supported features—Available for the printing of all SAP document types (SAPScript, Smartforms, ABAP)
RICOH IM 3500 Smart Device Connector
Smart devices are seeing greater and greater use on the
business scene, but procedures for connection to office
equipment are complex and still by no means stress-free.
With our Smart Device Connector, those complex procedures
become simple, and you can seamlessly connect to various
smart devices.
You can also operate a multifunction product by NFC or QR
code, simply holding the smart device over it, and you’re
connected.
